Type | Thermocouple(J,K,T,E,B,R,S,N,L,U,P,C,D),RTD(PT100(DIN),PT100(JIS)), Current(mA),Voltage(Volts) |
Resolution | 18 Bits |
Sampling Rate | 5 Times / Second (200msec) |
Maximum Rating | 2VDC minimum, 12VDC maximum |
Temperature Effect | 1.5µV /°C for all inputs except mA input, 3.0µV /°C for mA |
Sensor Lead Resistance Effect Thermocouple | 0.2 µV /Ω; 3-wire RTD: 2.6°C /Ω of Difference of Resistance of two leads 2-wire RTD: 2.6°C /Ω of Sum of Resistance of two leads |
Burn-out Current | 200mA |
Common Mode Rejection Ratio(CMRR) | 120 dB |
Normal Mode Rejection Ratio (NMRR) | 55dB |
Range | 3mA to 27mA, -1.3V to 11.5V |
Remote Set Point | Option Available |
Input Impedance Current | 2.5Ω |
Voltage | 1.5MΩ |
Sampling Rate | 1.66 Times/Second |
Current Input | Sensor Break Detection Below 1mA for 4-20mA input, below 0.25V for 1 - 5V input, not available for other inputs Sensor Break Responding Time 0.1 Seconds |
Event Input | No. of Event Inputs 2 Logic Low -10V minimum, 0.8V maximum. Logic High 2V minimum, 10V maximum Functions See availability table in user manual |
