Type | Thermocouple(J,K,T,E,B,R,S,N,L,U,P,C,D),RTD(PT100(DIN),PT100(JIS)), Current(mA),Voltage(Volts) |
Temperature Effect | 1.5µV /°C for all inputs except mA input, 3.0µV /°C for mA |
Sensor Lead Resistance Effect Thermocouple | 0.2 µV /Ω; 3-wire RTD: 2.6°C /Ω of Difference of Resistance of two leads 2-wire RTD: 2.6°C /Ω of Sum of Resistance of two leads |
Type | Linear Current,Linear Voltage |
Range | 3mA to 27mA, 1.3V to 11.5V |
Remote Set Point | Option Not Available |
Input Impedance Current | 2.5Ω |
Voltage | 1.5MΩ |
Sampling Rate | 1.66 Times/Second |
Current Input | 280mA maximum |
Voltage Input | 12VDC maximum |
Current Input | Sensor Break Detection Below 1mA for 4-20mA input, below 0.25V for 1 - 5V input, not available for other inputs Sensor Break Responding Time 0.1 Seconds |
Event Input | No. of Event Inputs 1 Logic Low -10V minimum, 0.8V maximum. Logic High 2V minimum, 10V maximum Functions Refer to user manual |
CT Input | CT Type CT98-1 |
Input Impedance | 294Ω |
Measurement Range | 0 to 50A AC |
Output of CT | 0 to 5V DC |
Sampling Rate | 1 Time/Second Output 1 /Output 2 |
Type Relay | Pulsed Voltage,Linear Voltage and Linear Current |
